Thunder Creek Trailers DW990UB

DOUBLE WALL FUEL TANK

• 10 Gauge Steel Tanks
• Lockable Enclosure for Pumps, Vents, Fill Ports
• 2” Roll Bar Around Tank, Vents and Fill Ports
• Tank Bolts to Chassis with Built-In Lift Points
• 110% Fuel Containment
• Outer Tank can be separated for Inspection
• 16” Manhole in Primary Tank for Inspection
• Emergency Shut-Off

TRAILER

• 7.5” x 1/4” Formed Frame
• Dexter® Torsion Axles and EZ Lube Hubs
• Electric Brakes with Breakaway Safety System
• 10-Ply Tires, ST235/80R16, Load Range E with Steel Wheels
• 7,000 lb. Enclosed Jack and Safety Tow Chains
• DOT Placards, Reflective Tape, LED Lights
• Replaceable, Bolt-on Fenders
• Dual Coat Gray Polyurethane Paint
• Replaceable Diamond Plate Rock Guard
• Adjustable Height 2 5/16” Ball Hitch
• Wiring Wrapped in Protective Braid

FRONT ENCLOSURE

• Automatic Interior LED Lighting
• 12V Deep Cycle Marine Battery
• Lockable Hatch-Style, Weather-Sealed Doors
• Fire Extinguisher

PUMP ENCLOSURE

• Fully Contained Pumping Area
• Lockable Hatch-Style, Weather-Sealed Doors
• Automatic Interior LED Lighting
• See Pumping System Options for Fuel Pump Configuration

OPTIONS
Items with + can be added any time to expand the functionality of the trailer as your operation grows.

TRAILER OPTIONS

•  Aluminum Wheels
• 14-Ply Tires, ST235/85R16, Load Range G
• Custom Paint Color
• Solar Battery Maintainer +
• Electric/Hydraulic Jack +
• 100 Gallon DEF Delivery System (details below) +
• 30 Gallon Auxiliary Oil Tank and 3 GPM Pump +
• Gear Drive 8 GPM Pump Upgrade for Oil Tank
• Five Drawer Tool Chest for Front Enclosure +
• Spill Containment Kit +
• Static Discharge Reel +
• Stationary Side Step +

REAR UTILITY BOX OPTIONS*

• Rear Utility Box (41.75”d x 58.75w x 49.75”h)
• Five Drawer Tool Chest for Utility Box +
• Can+Towel Holder +
• Two Drawer Low Boy Tool Chest +
• Work Bench with Vise +
• 35 lb. Grease Kit +
• Welder+Comp+Gen with 50’ Air/Elec. Combo Reel +
• Comp+Gen with 50’ Air/Elec. Combo Reel +
• 35 CFM Air Compressor with 50’ Air Hose Reel +

*Available on DW990UB model only

DIESEL EXHAUST FLUID OPTIONS

• DEF Delivery System +
• 100 Gallon HDPE Tank
• Bi-Directional Pump
• 35’ DEF Hose Reel
• Digital DEF Meter +
• 50’ DEF Hose Reel
• 120V DEF Heater +
